Part Details | ANNULAR BALL BEARING
3110-00-821-2384 A cylindrical device in which the inner or outer ring turns upon a single or double row of hardened balls which roll easily between the two rings, thus minimizing friction. For items with faces specially ground for duplex mounting see BEARING, BALL, DUPLEX. Excludes BEARING, BALL, AIRFRAME.
Alternate Parts: RB18, C82453, C8245-3, 3110-00-821-2384, 00-821-2384, 3110008212384, 008212384
| Supply Group (FSG) | NSN Assigned | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | APR 23, 1972 | 00-821-2384 | 00014 ( BEARING, BALL, ANNULAR ) |
REFERENCE DRAWINGS & PICTURES
SINGLE ROW BALL, INTERNAL SELF-ALIGNING, INNER RING EXTENDS BOTH SIDES, WITH TWO SETSCREWS IN INNER RING
Cross Reference | NSN 3110-00-821-2384
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| RB18 | 02695 | MORSE INDUSTRIAL CORPSEALMASTER BEARING DIV |
| C8245-3 | 76727 | NEW ENGLAND TRAWLER EQUIPMENT CO |
Technical Data | NSN 3110-00-821-2384
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | SINGLE ROW BALL, INTERNAL SELF-ALIGNING, INNER RING EXTENDS BOTH SIDES, WITH TWO SETSCREWS IN INNER RING |
| BORE DIAMETER | 1.1250 INCHES NOMINAL |
| OVERALL OUTSIDE DIAMETER | 62.00 MILLIMETERS NOMINAL |
| OUTER RING WIDTH | 0.8750 INCHES NOMINAL |
| INNER RING WIDTH | 1.6250 INCHES NOMINAL |
| LUBRICATION MATERIAL | GREASE |
| LUBRICATION MATERIAL DOCUMENT AND CLASSIFICATION | OD-G-24508 MIL SPEC SINGLE MATERIAL RESPONSE |
| STANDARD TOLERANCE DESIGNATION | ABEC NO.1 |
| BORE SHAPE | STRAIGHT |
| SURFACE FINISH | GROUND |
| RETAINER FABRICATION METHOD | PRESSED |
| SEAL QUANTITY | 2 |
| BEARING SEAL TYPE | LABYRINTH |
| LOAD DIRECTION | RADIAL |
| INTERNAL FIT-UP DESIGNATION | STANDARD |
| SPECIAL FEATURES | NO OIL HOLES OR GROOVES ALSO NO MEANS OF RE-LUBRICATION |
