NSN 4730-00-095-0808
Part Details | TUBE CAP
4730-00-095-0808 A tube fitting primarily designed for permanent installation during tubing system operation to fit over or butt against a tube or fitting for sealing. See also CAP, PROTECTIVE, DUST AND MOISTURE SEAL and CAP-PLUG, PROTECTIVE, DUST AND MOISTURE SEAL.
Alternate Parts: ANSI B16.22, 268L65654M00, 268L65654-M00, W7008, W-7008, 4730-00-095-0808, 00-095-0808, 4730000950808, 000950808
| Supply Group (FSG) | NSN Assigned | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | DEC 10, 1972 | 00-095-0808 | 06074 ( CAP, TUBE ) |
REFERENCE DRAWINGS & PICTURES
PLAIN
CAP
Cross Reference | NSN 4730-00-095-0808
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| ANSI B16.22 | 80204 | AMERICAN NATIONAL STANDARDSINSTITUTE, INCORPORATED |
| 268L65654-M00 | U2692 | JOHNSON CONTROLS LTD YORK NAVY SYSTES |
| W-7008 | 41947 | MUELLER BRASS |
Technical Data | NSN 4730-00-095-0808
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | CAP |
| CONNECTION STYLE | PLAIN |
| TUBE OUTSIDE DIAMETER FOR WHICH DESIGNED | 0.750 INCHES NOMINAL |
